Pentair IntelliCenter® i8P Personality Card Circuit Board | 521977z

The Pentair IntelliCenter i8P Personality Card Circuit Board, part number 521977Z, is an expansion card for the Pentair IntelliCenter pool and spa control system.

Key Features and Functionality

• Expansion Card: It is designed to be a "daughter card" that connects to the main i5P circuit board within the IntelliCenter system.



• System Upgrade: This card allows you to upgrade an existing IntelliCenter system to an i8P configuration, which provides more control over pool and spa equipment. It's also used as a replacement for a faulty i8P personality card.



• Increased Capacity: The i8P personality card is part of a system that can support more relays and circuits than the base i5P system, allowing for control of additional features like pumps, lights, and other accessories. A full i8P kit typically includes the personality card and additional relays.



• Compatibility: It is specifically designed for the Pentair IntelliCenter system. The card expands the capabilities of the main i5P board.



Installation

• Installation of this circuit board should be performed by a licensed or certified electrician or a qualified pool professional.

• It is crucial to turn off all AC power to the system at the main house circuit breakers before attempting any installation or service.

• The personality card must be installed in a designated slot (usually Slot 1) on the main motherboard.

• The installation guide for the IntelliCenter system provides detailed instructions and safety warnings.

Pricing and Availability

• Prices for the 521977Z circuit board can vary depending on the retailer, but it is typically priced in the range of several hundred dollars.

• Availability may also vary, with some retailers having it in stock while others may require a special order with an extended lead time due to potential manufacturing backlogs.
