Product Overview

The Pentair A&A Light Gray G4 Adjustable Orifice Complete Head | 230143 is a genuine replacement in-floor cleaning head designed for compatible Pentair A&A Gamma Series 4 pool cleaning and circulation systems.

Built with an improved adjustable-orifice design, the G4 cleaning head provides four different flow-rate settings, allowing installers and service professionals to fine-tune water distribution throughout the pool. Proper adjustment helps maximize circulation, improve debris movement, and optimize the performance of the entire in-floor cleaning system.

The 230143 features a light gray finish that blends cleanly with many popular plaster, pebble, quartz, and aggregate pool finishes. Upgraded springs and stronger internal construction provide improved durability for long-term operation in demanding swimming pool environments.

This model is supplied as the complete adjustable-orifice cleaning head assembly without the riser. Customers requiring the Light Gray version supplied with a riser should use Pentair part 222002.

Key Features

• Genuine Pentair A&A replacement component
• Gamma Series 4 / G4 cleaning head
• Adjustable-orifice design
• Four selectable flow-rate settings
• Light gray finish
• Improved water distribution
• Helps move debris toward collection areas
• Supports effective pool circulation
• Enhanced spring design
• Stronger construction for improved durability
• Designed for compatible A&A in-floor systems
• Retrofit-compatible with appropriate Gamma Series installations
• Complete cleaning head assembly
• Riser not included
• Manufacturer Part Number 230143

Product Specifications

Adjustable Orifice Technology

The G4 adjustable-orifice design allows water output to be tailored according to the location of each cleaning head.

With four available flow settings, installers can balance the in-floor system so that different areas of the swimming pool receive the appropriate amount of water movement.

This helps improve circulation while directing dirt and debris toward the pool's designated collection or suction points.

Enhanced Construction

Pentair designed the newer G4 head with upgraded internal components, including stronger construction and improved springs.

These enhancements help provide consistent pop-up action and reliable operation through repeated cleaning cycles.

Light Gray Finish

The light gray color is designed to blend with many modern swimming pool interiors, including:

• Light gray plaster
• Pebble finishes
• Quartz finishes
• Aggregate surfaces
• Contemporary pool interiors

Matching the correct cleaning-head color helps maintain a clean, finished appearance across the pool floor.

Important Part Number Notice

Pentair 230143 does not include the riser.

If your installation requires a complete Light Gray G4 Adjustable Orifice Head with riser, order:

Pentair 222002 – G4 Adjustable Orifice Complete Head with Riser, Light Gray

Always verify the existing cleaning system and required configuration before ordering.

Frequently Asked Questions

What system does Pentair 230143 fit?

It is designed for compatible Pentair A&A Gamma Series 4 / G4 in-floor cleaning systems.

What color is the 230143?

The cleaning head is Light Gray.

Is the orifice adjustable?

Yes. The G4 design provides four different flow-rate settings.

Does Pentair 230143 include the riser?

No. 230143 is the complete adjustable-orifice head without the riser.

What part number includes the Light Gray head with riser?

The corresponding Light Gray G4 Adjustable Orifice Complete Head with riser is Pentair 222002.

Why are there different flow settings?

The adjustable flow settings allow installers to balance water distribution throughout the in-floor cleaning system based on each head's location.

Is this just the internal pop-up portion?

No. The 230143 is sold as a complete G4 adjustable-orifice cleaning head assembly, but it does not include the separate riser.
