Product Overview

The Raypak P-R336A-EN-C #51 Digital Natural Gas Pool and Spa Heater | 009222 is a high-capacity residential heater designed specifically for installations located from 2,000 to 6,000 feet above sea level.

This model delivers 332,500 BTU of natural-gas heating input and features a copper fin-tube heat exchanger, corrosion-resistant polymer headers, digital electronic controls, and electronic ignition. Built-in diagnostics and Raypak’s ProTek Shield™ help provide dependable operation, convenient temperature management, and easier troubleshooting.

Key Features

• 332,500 BTU natural-gas heating input
• Factory configured for elevations from 2,000–6,000 feet
• Digital temperature display and controls
• Electronic ignition with no standing pilot
• Copper fin-tube heat exchanger
• Corrosion-resistant polymer headers
• Built-in operating and service diagnostics
• ProTek Shield corrosion-protection module
• Automatic internal bypass
• Unitherm Governor for condensation protection
• High-wind-resistant design
• 2-inch plumbing connections
• Dual-voltage electrical capability
• Compatible with supported pool automation systems
• Designed for residential pools and spas

Benefits

• Provides powerful heating for large residential pools and spas
• Factory altitude configuration supports qualifying high-elevation installations
• Copper tubing provides efficient heat transfer
• Polymer headers resist rust and corrosion
• Digital controls provide accurate temperature management
• Electronic ignition eliminates the need for a standing pilot
• Self-diagnostics assist technicians with troubleshooting
• ProTek Shield helps protect critical heat-exchanger components
• Low-profile construction provides convenient equipment-pad access

Specifications

Compatibility Information

The Raypak 009222 is designed for residential pool and spa systems using natural gas at elevations from 2,000 to 6,000 feet.

Before ordering, verify:

• Installation elevation
• Natural-gas meter capacity
• Gas-line size and inlet pressure
• Pool and spa volume
• Required heating recovery time
• Plumbing size and water flow
• Available electrical service
• Equipment-pad clearances
• Ventilation requirements
• Pool automation compatibility
• Local gas, electrical, and building codes

This is a residential non-ASME model. An ASME-certified heater may be required for commercial, public, or code-regulated installations.

What’s Included

• Raypak 009222 natural-gas pool and spa heater
• Copper fin-tube heat exchanger
• Polymer header assembly
• Digital temperature control system
• Electronic ignition system
• ProTek Shield protection module
• Factory-installed internal bypass components
• Manufacturer installation documentation

Not Included: Gas piping, gas shutoff valve, electrical wiring, plumbing materials, venting components, automation wiring, equipment pad, pressure-relief valve, or installation labor.

Installation Information

Professional installation by a qualified gas or pool-equipment technician is required.

The installer must verify the installation elevation, gas-meter capacity, gas-line sizing, inlet and manifold gas pressure, electrical service, water flow, plumbing configuration, ventilation, combustion-air requirements, equipment clearances, and local code compliance.

This heater is factory configured for natural gas and elevations from 2,000 to 6,000 feet. It should not be installed outside that elevation range without confirming the correct Raypak configuration.

Do not connect this heater to propane gas unless a manufacturer-approved conversion is available and completed by a qualified professional.

Warranty Information

The Raypak 009222 is covered by a limited manufacturer warranty subject to Raypak’s current warranty terms, application, purchase channel, installation date, product registration, and professional-installation requirements.

Proof of purchase and professional installation documentation may be required.

Warranty coverage does not include damage caused by:

• Incorrect altitude configuration
• Improper gas pressure or gas-line sizing
• Incorrect fuel connection or unauthorized conversion
• Restricted or excessive water flow
• Poor or unbalanced water chemistry
• Scale, corrosion, or erosion
• Freezing
• Improper ventilation or venting
• Incorrect electrical installation
• Misuse or unauthorized modifications

Commercial use may receive different warranty coverage than a qualifying residential installation.

Freight Delivery Notice

This heater ships by freight.

Inspect the cabinet, controls, plumbing connections, and packaging carefully before signing the delivery receipt. All visible damage must be documented on the carrier’s paperwork, and photographs should be taken immediately.

Do not sign for a visibly damaged shipment as being received in good condition. Concealed shipping damage must be reported promptly after delivery.

Customer Questions

Is this heater natural gas or propane?
The Raypak 009222 is factory configured for natural gas.

What is the heater’s BTU rating?
It has a natural-gas input rating of 332,500 BTU.

What elevation is this model designed for?
This #51 configuration is designed for installations from 2,000 to 6,000 feet above sea level.

What type of heat exchanger does it use?
It uses a copper fin-tube heat exchanger.

Does it have bronze headers?
No. This residential non-ASME model uses corrosion-resistant polymer headers.

Does it have electronic ignition?
Yes. It uses electronic ignition and does not have a continuously burning standing pilot.

Is this an ASME heater?
No. This is a residential non-ASME model.
