Product Overview
The Pentair Clean and Clear Plus 420 sq. ft. Cartridge Filter | 160301 is a high-capacity cartridge filter designed for dependable pool water clarity, strong flow performance, and easier maintenance compared to traditional backwash-style filters. Built with a durable fiberglass-reinforced polypropylene tank and a four-cartridge internal design, the Clean and Clear Plus 420 provides a large filtration area to capture dirt, debris, and fine particles while extending time between cleanings.
With 420 square feet of filtration area, 2" plumbing, and up to 150 GPM design flow, this filter is a strong choice for residential in-ground pools that need reliable filtration performance and reduced water waste.
Ideal For
Residential in-ground swimming pools
Pool owners wanting a large-capacity cartridge filter
Systems requiring up to 150 GPM flow
Customers replacing an existing Pentair CCP420 filter
Pools where backwashing is not preferred
Equipment pads using 2" plumbing
Large residential pools needing extended filter cycles
Key Features
420 sq. ft. cartridge filter area
Four-cartridge internal design for increased dirt-holding capacity
No backwashing required
Durable fiberglass-reinforced polypropylene tank
2" plumbing for strong system flow
150 GPM design flow rate
50 PSI maximum working pressure
Clamp ring design for cartridge access
Continuous High Flow internal air relief
Easy-access drain for clean-out and winterization
Balanced hydraulic flow design
ANSI/NSF Standard 50 certified
Benefits
The Pentair Clean and Clear Plus 420 helps keep pool water clean and clear while reducing routine maintenance. Its large 420 sq. ft. filter area allows the filter to hold more debris before cleaning is needed, helping extend the time between service intervals.
Unlike sand or DE filters that require backwashing, this cartridge filter can be cleaned by removing the cartridges and rinsing them with a garden hose. This helps reduce water waste and makes it a strong option for customers who want simple, efficient pool filtration.
The fiberglass-reinforced tank is built for strength and corrosion resistance, while the 2" plumbing and balanced hydraulic design support strong water flow for residential pool systems.
Specifications
| Specification | Details |
|---|---|
| Brand | Pentair |
| Product Line | Clean and Clear Plus |
| Model | CCP420 |
| Product Type | Cartridge Filter |
| SKU / Part Number | 160301 |
| Barcode / UPC | 788379670139 |
| Filtration Area | 420 sq. ft. |
| Design Flow Rate | 150 GPM |
| Maximum Flow Rate | 150 GPM |
| Maximum Working Pressure | 50 PSI |
| Plumbing Size | 2" |
| Pipe Size | 2" |
| Cartridges Required | 4 |
| Tank Material | Fiberglass-reinforced polypropylene |
| Tank Color | Beige |
| Tank Diameter | 22.98" |
| Product Height | 49" |
| Shipping Dimensions | 22" x 22.5" x 45" |
| Product Weight | 75 lbs |
| Side Clearance | 6" |
| Vertical Clearance | 68" |
| 6-Hour Turnover Capacity | 54,000 gallons |
| 8-Hour Turnover Capacity | 72,000 gallons |
| 12-Hour Turnover Capacity | 108,000 gallons |
| Standards / Certifications | ANSI Standard 50 Certified |
| Manufacturer | Pentair |
Warranty & Compatibility
Professional installation is recommended for proper plumbing connection, pressure testing, and safe system startup. Before ordering, confirm filter size, plumbing size, equipment pad clearance, flow rate, cartridge requirements, and replacement model compatibility.
This filter is commonly used as the Pentair CCP420 and should be matched to the pool’s pump flow rate, plumbing layout, and required filtration capacity.
Customer-Facing Q&A
Q: What model number is this filter?
A: This listing is for the Pentair Clean and Clear Plus 420 sq. ft. Cartridge Filter, model 160301 / CCP420.
Q: How many square feet is this filter?
A: This filter has 420 sq. ft. of cartridge filtration area.
Q: How many cartridges does it use?
A: The Pentair 160301 uses 4 internal filter cartridges.
Q: Does this filter require backwashing?
A: No. Cartridge filters do not require backwashing. The cartridges are removed and rinsed for cleaning.
Q: What is the flow rate?
A: The listed design flow rate is 150 GPM.
Q: What plumbing size does this filter use?
A: This filter uses 2" plumbing connections.
Q: What is the maximum working pressure?
A: The maximum working pressure is 50 PSI.
Q: How much does the Pentair 160301 weigh?
A: The listed product weight is approximately 75 lbs.
Q: Is this the same as the CCP420?
A: Yes. Pentair 160301 is commonly referred to as the Clean and Clear Plus CCP420 cartridge filter.
Q: Should this filter be professionally installed?
A: Yes. Professional installation is recommended for proper plumbing, pressure testing, and safe operation.
