Product Overview

The Pentair IntelliCenter 523969 is a high-capacity pool and spa automation system designed for dual-equipment pool and spa installations. Unlike a PS shared-equipment system, the i10D configuration is designed for applications where the pool and spa operate with separate equipment sets, providing greater flexibility for larger and more advanced installations.

This complete IntelliCenter package combines the Load Center, i10D Personality Kit, IntelliChlor Plus40 Salt Chlorine Generator, integrated salt-system transformer, and High Power Wireless connectivity into one centralized automation system.

The i10D configuration provides expanded relay capacity for controlling multiple pumps, heaters, lights, water features, blowers, and other auxiliary equipment.

What Does i10D Mean?

The “D” in i10D stands for Dual Equipment.

This configuration is different from an i10PS shared-equipment system. An i10D is intended for installations where the pool and spa have separate circulation or heating equipment, allowing the automation system to operate each body of water more independently.

IntelliChlor Plus40 Salt Chlorination

The included IntelliChlor Plus40 Salt Chlorine Generator is designed for pools up to 40,000 gallons.

At 100% output, the Plus40 produces up to approximately 1.40 pounds of chlorine per 24 hours.

The IntelliChlor system converts dissolved salt into chlorine and integrates directly with the IntelliCenter automation platform, allowing pool owners and service professionals to manage automation and chlorine production within the Pentair ecosystem.

Ideal For

This makes the i10D particularly useful for larger custom pools and spas that may have:

Separate pool and spa filtration pumps

Separate heaters

Multiple variable-speed pumps

Independent pool and spa circulation

Multiple lighting circuits

Water features

Spa blowers

Booster pumps

Landscape or equipment-pad auxiliary circuits

Key Features

i10D Dual Equipment configuration

Designed for pool and spa systems with separate equipment

IntelliCenter Load Center

10 relay-controlled circuits

Includes IntelliChlor Plus40 Salt Chlorine Generator

Salt cell rated for pools up to 40,000 gallons

Produces up to 1.40 lbs. of chlorine per 24 hours at 100% output

Integrated IntelliChlor salt-system transformer

Includes High Power Wireless

Color touchscreen interface

Remote monitoring and control through compatible Pentair applications

Programmable schedules

Control of compatible variable-speed pumps

Heater control

Pool and spa lighting control

Water-feature control

Auxiliary equipment control

Expandable IntelliCenter platform

Valve actuators are not included

Specifications

What's Included

• Pentair IntelliCenter Load Center
• i10D Personality Kit
• i5P motherboard
• i10D daughter card
• Relay configuration supporting up to 10 circuits
• IntelliChlor Plus40 Salt Chlorine Generator
• IntelliChlor salt chlorine generator transformer
• High Power Wireless connectivity
• IntelliCenter outdoor control panel
• Required IntelliCenter system electronics

Not Included

• Valve actuators are not included
• Additional expansion hardware unless otherwise specified

i10D vs. i10PS

The most important difference is the equipment configuration. Choose the i10D when the pool and spa operate with separate equipment and the i10PS when the pool and spa share major equipment.

Warranty & Compatibility

Replacement / Updated Part Number

Pentair 523969 replaces legacy IntelliCenter part number 523908.

The newer 523969 bundle incorporates Pentair's updated IntelliChlor Plus40 Salt Chlorine Generator while retaining the i10D dual-equipment IntelliCenter configuration.

Customer-Facing Q&A

Q: Does Pentair 523969 include a salt cell?
A: Yes. It includes the IntelliChlor Plus40 Salt Chlorine Generator.

Q: Does it include the IntelliChlor transformer?
A: Yes. The required salt chlorine generator transformer is included in the Load Center configuration.

Q: Does 523969 include valve actuators?
A: No. Pentair specifies 523969 without the two IntelliValve valve actuators.

Q: What size pool does the salt cell support?
A: The included IntelliChlor Plus40 is rated for pools up to 40,000 gallons.

Q: How much chlorine does the Plus40 produce?
A: The Plus40 produces up to approximately 1.40 lbs. of chlorine per 24 hours at 100% output.

Q: What is the difference between i10D and i10PS?
A: The i10D is designed for dual-equipment installations, while the i10PS is designed for pool/spa systems sharing major equipment.

Q: Does it include wireless connectivity?
A: Yes. The 523969 bundle includes High Power Wireless connectivity.

Q: Can it control variable-speed pumps?
A: Yes. IntelliCenter is designed to integrate with compatible Pentair variable-speed pumps and other supported pool equipment.

Q: What older part number does 523969 replace?
A: Pentair 523969 replaces 523908.
