Product Overview

The Pentair IntelliFlo3 VSF 1.5 HP Pool Pump combines variable-speed operation, sensorless flow control, and smart connectivity in a compact, energy-efficient design. Built for residential inground pools and spas, it can operate at a selected motor speed or automatically adjust its speed to maintain a programmed flow rate as system conditions change.

Wi-Fi and Bluetooth connectivity allow the pump to be programmed, monitored, and controlled through the Pentair Pool app. Pool owners can create customized schedules for filtration, heating, cleaning, sanitation, and water features without requiring a separate pump-mounted display.

With dual-voltage capability, a wide 400–4,000 RPM operating range, eight customizable programs, and included 1.5-inch/2-inch unions, the IntelliFlo3 VSF 011065 provides flexible installation and precise circulation control for smaller and medium-size pool systems.

Key Features

Variable Speed and Flow Control
Operate the pump by speed or program a flow rate between 20 and 90 GPM. The pump automatically adjusts its motor speed to help maintain the selected flow.

Pentair Pool App Connectivity
Built-in Wi-Fi and Bluetooth connectivity provide remote programming, monitoring, scheduling, and operating control through a compatible mobile device.

Eight Customizable Programs
Create up to eight speed or flow programs using manual, timer, or scheduled operating modes.

Dual-Voltage Installation
Supports 115V and 208–230V electrical systems, providing flexibility for new installations and qualifying replacement applications.

Energy-Efficient Motor
The permanent-magnet, totally enclosed fan-cooled motor operates only as fast as the pool system requires, reducing unnecessary energy consumption.

Smart Equipment-Pad Upgrade Options
An optional relay control board allows the pump to control compatible pool equipment such as lights, salt chlorine generators, booster pumps, and other components.

Benefits

• Provides precise circulation using speed- or flow-based programming
• Helps reduce energy consumption compared with conventional single-speed pumps
• Supports remote monitoring and schedule changes through the Pentair Pool app
• Automatically compensates for changing system resistance in flow mode
• Operates quietly at lower programmed speeds
• Includes dry-start, loss-of-prime, and smart-priming protection features
• Compatible with Pentair automation systems through an RS-485 connection
• Suitable for filtration, heating, sanitation, cleaning, and water-feature applications

Specifications

Installation Information

The IntelliFlo3 VSF must be installed by a qualified pool professional or licensed electrician in accordance with national and local electrical, plumbing, bonding, and pool-safety requirements.

The pump requires GFCI-protected electrical service. At 115V, the pump draws up to 12 amps; at 208–230V, it draws approximately 6.4–5.9 amps. Electrical supply voltage, wire size, breaker size, bonding, plumbing diameter, and automation connections must be confirmed before installation.

Continuous electrical power must be supplied when the pump is connected to a Pentair automation system. Do not place the pump on the same switched circuit as unrelated lights or appliances.

Confirm Before Ordering

Confirm manufacturer part number 011065, available supply voltage, plumbing dimensions, equipment-pad clearance, flow requirements, automation compatibility, and intended application before purchasing.

This listing is for the 1.5 HP IntelliFlo3 VSF model. It should not be confused with the larger 3 HP IntelliFlo3 VSF pump or the discontinued original IntelliFlo VSF series.

A pump-mounted touchscreen is not included with this model. Standard programming is completed through the Pentair Pool app. A compatible Pentair touchscreen controller and relay control board are available separately.

Warranty Information

Pentair warranty eligibility and coverage depend on the purchase channel, installation method, product registration requirements, installer qualifications, and Pentair’s current warranty policy. Professional installation may be required for extended coverage.

Keep the original proof of purchase, installation invoice, model number, and serial number. Final warranty eligibility should be confirmed directly with Pentair before purchase or installation.

Customer Q&A

Can this pump operate on 115V?
Yes. Model 011065 supports 115V and 208–230V single-phase electrical service. The electrical connection must be configured correctly by a qualified installer.

Can it maintain a specific flow rate?
Yes. The pump can be programmed for flow rates from 20 to 90 GPM and automatically adjusts motor speed to maintain the selected flow within the system’s operating limits.

Does the pump include Wi-Fi?
Yes. Built-in Wi-Fi and Bluetooth connectivity allow control through the Pentair Pool app.

How many schedules can be programmed?
The pump supports up to eight customizable speed or flow programs using manual, timer, or schedule modes.

Does it include a touchscreen?
No. The pump is designed for app-based control. A compatible drive-mounted touchscreen controller is available separately.

Can it connect to Pentair automation?
Yes. IntelliFlo3 VSF pumps support Pentair automation through an RS-485 digital connection.

Are unions included?
Yes. The 1.5 HP model uses an included union kit suitable for 1.5-inch or 2-inch plumbing configurations.
